SCAN-APP

SCAN-APP

Category:

Description

HANDHELD ANDROID THERMAL DEVICE

Type: Thermal system
Frame rate: < 9Hz
Resolution: 384 x 288
Platform: Android/LINUX

HARDWARE
Minimal RequirementsAndroid 4.1 and above, supporting USB OTG
Imager384 x 288 microbolometer
LWIR 7.5 -14um
Optics6.8mm lens (55° x 41°)
13mm lens (29°x 22°)
19mm lens (19°x14°)
35mm lens (11° x 8°)
FocusManual, 0.2m to infinity
Frame Rate8.7Hz
Weight138 grams / 4.86 ounces
Size55 x 65 x 40mm (2.16 x 2.55 x 1.57in)
Operating Temperature-10°C to +50°C (14°F to +122°F)
Storage Temperature-20°C to +50°C (-4°F to +122°F)
Power SupplyNo battery, 5V over USB OTG cable, power consumption < 0.5W
CertificationsCE, FCC, RoHS
EncapsulationIP54
Mount/HandleErgonomic handle, using 1/4″-20 standard tripod mount
Device AttachmentClip-on for smartphone (5 -10cm span)
MEASUREMENT
Resolution384 x 288 pixels (>110,000 pixels )
Accuracy+/- 3°C or 3% (@25°C)
SensitivityNETD <0.07°C
Temperature Range Calibration5 – 90 °C
SOFTWARE
Viewing Modes• Night Vision
• Thermography (Basic)
OutputVideo & Audio (h.264), Snapshot
Color PalettesHot White / Hot Black / Iron /Rainbow / Grey / Vivid
ZoomContinuous digital zoom using touchscreen
Software and feature updatessYes (via Google Play)
MaintenanceBad pixel repair utility
